CAD/CAM Lab

Facilities available:

1.CNC Milling Machine

Software Available with us are:

<!--[if !supportLists]-->1.     <!--[endif]-->MASTERCAM Software (For 20 users):

Features: Programming of FBM - automatically program pockets, contours, and drilled holes, Dynamic Milling, High Speed Machining, Complete tool path associability, Tool path data can be stored directly in the solid works file, Stream lined multi axis programming, Powerful 2D Machining, 3D Roughing, Finishing & Clean up Machining, Powerful Roughing & Finishing, Easy Threading & Grooving, Feed Rate Optimization, Efficient NC Tools and Tool Path Management.

2.     SOLIDWORKS Software (For 60 users):

<!--[if !supportLists]-->·         <!--[endif]-->SOLIDWORKS Premium Software

<!--[if !supportLists]-->·         <!--[endif]-->SOLIDWORKS Simulation Premium

<!--[if !supportLists]-->·         <!--[endif]-->SOLIDWORKS Motion

<!--[if !supportLists]-->·         <!--[endif]-->SOLIDWORKS Flow Simulation

<!--[if !supportLists]-->·         <!--[endif]-->SOLIDWORKS Plastics

<!--[if !supportLists]-->·         <!--[endif]-->SOLIDWORKS Sustainability

<!--[if !supportLists]-->·         <!--[endif]-->Complete Curriculum,

<!--[if !supportLists]-->·         <!--[endif]-->Teacher Guide and Student Guides

<!--[if !supportLists]-->·         <!--[endif]-->Extensive interactive Courseware projects

<!--[if !supportLists]-->·         <!--[endif]-->Access to our online educational community

Metrology Lab

Metrology Lab in our department is equipped with various measuring instruments, gauges and measuring machines. It makes the students to understand the basic principle involved in measuring process that suits for the respective product and its importance in the quality control. The experiments are based on geometrical measurements, form measurements using various basic measuring instruments like all types of vernier, micrometer and dial gauges etc and using coordinate metrology (Profile Projector). The students are exposed to learn about the error involved in the measurements, calibration of measuring instruments. The students are utilizing it.

The five major equipments in the lab are

<!--[if !supportLists]-->1.      <!--[endif]-->Tool Makers microscope with accessories with radius measuring head and thread template ocular

<!--[if !supportLists]-->2.      <!--[endif]-->Slide and profile projector

<!--[if !supportLists]-->3.      <!--[endif]-->Large tool maker microscope

<!--[if !supportLists]-->4.      <!--[endif]-->Surface roughness tester

<!--[if !supportLists]-->5.      <!--[endif]-->Gear Rolling tester

Machine Tool Laboratory (Production workshop)

The Workshop supports to conduct practical classes manufacturing processes for students belonging to students of Production engineering. The major equipment available in Workshop are tabulated below. List of Equipments available at Workshop are as below



<!--[if !supportLists]-->1.      <!--[endif]-->Different Drilling machines are available

 a) High precision type Drilling machine

b)  Cylindrical Grinding machine universal type (Height 178 mm Grinding Diameter 254 mm length up to 1015 mm)

c) Radial Drilling machine

<!--[if !supportLists]-->2.      <!--[endif]-->Grinding machines

A) Hi life centerless grinding machine

B) Tool and Cutter grinding machines

C) Alex Machine made surface grinder table size 600 mm x 200 mm (Longitudinal travel 650mm and gross travel 225 mm)

D)  Bench Grinder

<!--[if !supportLists]-->3.      <!--[endif]-->Press machine like

A) Fly wheel type Double pillar type hand press machine

B)  Mechanical power press (Capacity 25 tonnes, stroke 63 mm)

<!--[if !supportLists]-->4.      <!--[endif]-->Different Lathe machines are available

 A) HMT lathe machine

B) Turret Lathe machine

C) Capstone lathe

D) The master batch lathe

<!--[if !supportLists]-->5.      <!--[endif]-->Welding machines are also available

A) Spot welding machine (400 V/10KVA capacities)

B) Automatic Welding machine Carriage mounted (SAW Machine)

<!--[if !supportLists]-->6.      <!--[endif]-->Milling machine available with us are

A) Universal Type milling machine (Hungary make)

B) CNC milling machine (Small size)

C) Thread milling machine

D) Three Dimensional pantograph milling machine

<!--[if !supportLists]-->7.      <!--[endif]-->In addition we also have some other machines which are used for some specific industries

A) Hobbing Machine

B) Shaper Machine

C) Tool Lapping machine

D) Spark Erosion Machine

<!--[if !supportLists]-->8.      <!--[endif]-->To do hands-on practice, we also have HMT CNC Train Master, Oil hydraulic trainer



Computer lab

Desktop Computer (Purchase under TEQUIP-II) with latest configuration with internet connectivity for students.
